Chain Conveyors

Motorised conveyor, chain driven

Medium duty conveyors

Ideal for handling medium duty products with roller ratings up to 300kgs.

Roller to roller fixed drive as standard with tangential drive option.

Adjustable friction rollers available where accumulation is required.

(Typical example from this range is 60mm dia rollers @ 100mm pitch mounted 75 x 50 x 6 angle frames)

Chain Driven roller conveyors are the ideal solution for handling wide materials where other powered options may be restricted.


heavy duty chain conveyor

Heavy duty  conveyors

Ideal for handling heavy duty products with roller ratings up to 500kgs.

Roller to roller fixed drive as standard with tangential drive option.

Frames and stands available in mild steel, stainless steel and galvanised with a comprehensive colour range.

(Typical example from this range is 80mm dia rollers @ 150mm pitch mounted in 100 x 65 x 7 angle frames)

Chain conveyors can often be integrated into systems for transferring products 90 degrees.


Extra Heavy Duty Powered by chain conveyor

Extra heavy  conveyors

ideal for handling extra heavy duty products with roller rating up to 1500kgs.

Roller to roller fixed drive only.

Full range of roller diameters and widths available in mild steel, zinc plated and stainless steel.

(Typical example from this range is 114mm dia rollers @ 200mm pitch mounted on 100 x 50 channel frames using pillow block bearings

We can offer a full range of chain conveyors in a choice of medium or heavy duty either with steel or plastic chains.


Motorised bend powered by chains

Chain conveyor Bends

We offer a full range of chain driven powered roller bends in medium/heavy and extra heavy duties to suit all straight section widths and types.

Standard angles are 45 and 90 degrees but any angle will be considered depending on roller type and application.

Standard inside radiuses start at 900mm but again any inside radius will be considered.

We offer a full range of chain driven roller types to include tapered roller, straight roller etc. all with finishes to include zinc plated and PVC.
